HS Series 380 kV 210 kN Composite Suspension Type Insulators

HS Series  Composite Suspension Type Insulators

These types composite insulators used in high voltage transmission power lines. These insulators are preferred because of their advantages, areas close to the sea and industrial pollution in regions of high hydrophobic properties to the high insulation to provide better, be impenetrable type, easy assembly, according to the porcelai insulator and glass insulator to the lighter.

İlgili Videolar

Technical Features

Unit

380 kV 210 kN

Total Leakage Current Length

 mm

  : 9075

Tensile Strength Frequency Humid in 1 Minute

 kV

 : 570

Resistence to Lightning Stroke

 kVpeak

 : 1425

Minimum Mechanical Tensile Strength

 kN

 : 210

Rated Frequency

 Hz

 : 50

Distance Between Metal Sections

 mm

 : 2600

Section Height

 mm

 : 2990

Silicon Color

 : HTV / light grey

Metal Fastening Product

 : Hot-dip galvanized forged steel

Metal Fastening Product Lenght

 : IEC 60120

Applied Standards

 : IEC 61109, IEC 62217
